Blok
Made in UK
5 Year Warranty
IP20 Rated
CE
Key Features
Body constructed from powder coated steel
High transmission opal diffuser
Microprism diffuser available to aid in achieving UGR<19
Tridonic or Philips LED modules and drivers
Stand-alone or continuous run lighting system
Downlight only or up/downlight
High colour rendering CRI>80
High colour consistency 3 step MacAdam
Bespoke sizes, shapes and outputs made to order
Corner section made to order
Various powder coated finishes
Infill blanking panels optional
IP20 rated
Wireless option available
LiFePO4 Lithium Battery for extended emergency life
5 year warranty on LED system
Download Data Sheet (PDF)
Technical Dimensions
Click to expand
Linear Profiles
Blok
Body Size
1205mm
1505mm
Custom
Distribution
Downlight Only
Uplight / Downlight
Mounting
Surface Mount
Suspended Mount
Configuration
Stand-alone
Continuous Centre
Continuous Start
Continuous End
Driver
Standard
DALI
Wireless Dim
1-10V
Touch Dimming
Output (Size-Dependent)
Colour Temperature
3000K
4000K
5000K
6500K
Sensor
No Sensor
PIR Sensor
Emergency (LiFePO4)
No Emergency
3 Hour Emergency
Self-Test 3 Hour Emergency
DALI EM Pro 3 Hour Emergency
Wireless Emergency
Diffuser
Opal
Microprism
Body Colour
White
Black
Silver
Custom
Generated Specification Code
BL-12-D-SF-SA-S-04-3---OP-W
๐
Use this code to request a quote or specify this product in your lighting plans.
Request Quote / Consultation
