Shuttle 150
Spotlights
Shuttle 150
Made in UK
5 Year Warranty
IP20 Rated
CE
Key Features
Body constructed from powder coated steel
Passive cooling aluminium heat sink
Tridonic LED modules and drivers
Supplied with adjustable 3m drop wire suspension kit
Downlight only
Surface mounting option available
Track mounting option available
Small colour tolerance
3 step MacAdam CRI 80/90/95
2 step MacAdam CRI97
Various powder coating finishes
Xicato LED available
IP20 rated
Wireless option available
5 year warranty on LED system
Download Data Sheet (PDF)
Technical Dimensions
Click to expand
Spotlights
Shuttle 150
Mounting Option
Surface Monopoint Ceiling Base
Wire Suspended Pendant (3m Drop Kit)
3-Circuit Track Mounted Adapter
Suspension Kit
Single Wire Suspension
Ceiling Rose with Suspension
Body Length
260mm Cylinder
450mm Cylinder
Driver
Standard
DALI
Wireless Dim (Casambi)
1-10V
Touch Dimming
Output (Size-Dependent)
Colour Rendering Index
Ra > 80 (Standard)
Ra > 90 (High Fidelity)
Colour Temperature
2700K
3000K
4000K
Beam Angle / Reflector
10° Narrow Spot Reflector
30° Medium Reflector
45° Wide Reflector
Finish / Colour
White (RAL 9016)
Black (RAL 9005)
Silver (RAL 9006)
Custom
Cable Colour
White PVC (3m)
Black PVC (3m)
Grey PVC (3m)
Transparent Flex (3m)
Generated Specification Code
ST15-SF-2-S-10-S-2-10-W-W
📋
Use this code to request a quote or specify this product in your lighting plans.
Request Quote / Consultation
